特征提要 ( General Specifications )
| 吃瓜网
定子毗连体例 ( Winding Type ) | 星形 ( Star connection) |
| 霍尔捏造事实弯度 ( Hall Effect Angle ) | 120度电视场角 ( Electrical Angle of 120 degree) |
| 径向空隔 ( Radial Play ) | 0.02mm@450g |
| 径向洞眼 ( Axial Play ) | 0.08mm@450g |
| 大径向吃瓜网
负载 ( Max radial force ) | 5N 距法兰部10mm ( 10mm From the flange) |
| 较大 径向环境下 ( Max axial force ) | 2N |
| 介电难度 ( Dielectric Strength ) | 600VAC/1S |
| 耐压电阻器 ( Insulation Resistance ) | 100MΩ, 500VDC |
| 环境体温 ( Ambient Temperature ) | -20°C ~ +50°C |
| 耐压品质 (Insulation Class) | Class B |
接线申明(Electric Connection)
| 引入线类型Type | 引入线色相Color | 攻效Functions |
| UL1061 AWG28 | 黄白色 (Yellow ) | 霍尔交流电源正 ( Vcc ) |
| 蓝色系 ( Blue ) | 霍尔 U ( Hu ) |
| 橘黄色 ( Orange ) | 霍尔 V ( Hv ) |
| 浅棕色 ( Brown ) | 霍尔 W ( Hw ) |
| 纯白色 ( White ) | 霍尔电原负 ( GND ) |
| UL1007 AWG22 | 有机 ( Green ) | U相 ( Phase U ) |
| 灰黑色 ( Red) | V相 ( Phase V ) |
| 玄色 ( Black) | W相 ( Phase W ) |
机电能 (Electrical Specifications)
| 单 位 (Unit) | FL28CBLA38-24V-4012A | FL28CBLA48-24V-4524A |
| 极数 ( Number of poles ) |
| 8 |
| 相数 ( Number of phases ) |
| 3 |
| 格外电阻值 ( Rated voltage ) | VDC | 24 |
| 三倍惯量 ( Rated torque) | mN.m | 28 | 50 |
| 持续不断工作传动比 ( Continuous stall torque) | mN.m | 33.6 | 60 |
| 特别传输率 ( Rated speed ) | RPM | 4000 | 4500 |
| 增加马力 ( Rated power ) | W | 12 | 24 |
| 峰峰值力矩 ( Peak torque ) | mN.m | 84 | 150 |
| 基线交流电 ( Peak current ) | A | 2.0 | 4.5 |
| 线内阻 ( Line to line resistance ) | ohms@20℃ | 5.7 | 2.5 |
| 线电感 ( Line to line inductance ) | mH | 2.48 | 1.2 |
| 转距常数 ( Torque constant ) | mN.m/A | 42.8 | 36 |
| 反电势 ( Back EMF ) | Vrms/KRPM | 3.165 | 2.68 |
| 弹出惯量 ( Rotor inertia ) | g.cm2 | 5.8 | 7.3 |
| 手机直径 ( Motor length ) L | mm | 38 | 48 |
| 食用量 ( Weight ) | Kg | 0.095 | 0.12 |
新款上市建筑机电都可以依照投资者需全屋定制。
The motor can be designed &manufactured with customized request.
